Performance and Characteristics:

According to the demands of the market, this machine is designed and manufactured on the base of absorption of advantages in the same field from home and abroad.
It is a kind of colorful printing film hot cutting sealing bagmade equipment with multi functions and high quality.
With reasonable structure, wide use and breadth mechanism, it adopts computer control, highautomation, ease of operation, convenience of a djustment, the close location with high precision, stable feeding, tensionin balance; Automatic temperature control, automatic counting, alarming in sound; And also with color mark tracking endless time automatic stop etc features.
It is apply use PP, BOPP, HDPE, LDPE as raw material. It can finish automatic folding film, automatic adhesion, clamp pearlite ball film automatichydraulic, automatic holing in one time.

Feature:

1) Adopt electromechanical intergration, computer length setting, photoelectrical tracking, etc.
2) Suitable for making heating sealing and cutting bags that take PP, BOPP, HDPE, LDPE as raw material.
3) Suitable for packing cloth, hardware, plastic products production, stationery, food and households, industrial packages!

Type	RQL-500	RQL600	RQL700	RQL800	RQL-900	RQL-1000	RQL-1100	RQL-1200
Bag making speed	30-150section/min
Bag making width	30-500mm	30-600mm	30-700mm	30-800mm	30-900mm	30-1000mm	30-1100mm	30-1200mm
Bag making length	35-1000mm	45-1000mm	55-1000mm	65-1000mm	75-1000mm	85-1000mm	95-1000mm	105-1000mm
Location precision	±0.5mm
Voltage	380/220V
Power	3.2kw	3.4kw	3.6kw	3.8kw	4.0kw	4.2kw	4.4kw	4.6kw
Overall size (L ×W ×H) mm	3600×1100×1800	3600×1200×1800	3600×1300×1800	3600×1400×1800	3600×1500×1800	3600×1600×1800	3600×1100×1800	3600×1200×1800
Weight	1380kg	1460kg	1540kg	1620kg	1700kg	1780kg	1860kg	1940kg
